Commercial Cooking
24″ Gas Range, 4 Burners
Model DRR24-4BRanges →
4
Burners
105,200 Btu/hr
Gas Output
| Brand | Drago |
| Burners | 4 |
| Gas Output | 105,200 Btu/hr |
| Certifications | cETLus, ETL-Sanitation |
| Width | 24" |
| Depth | 30" |
| Height | 37.5" |
| Shipping Weight | 260 lbs |
Specifications reflect DRAGO's current published catalog data. Confirm current specifications with DRAGO before purchase.
More than 30 years of experience
DRAGO brings decades of focus on commercial food service equipment.
Warranty programs
Refrigeration and gas-equipment warranty coverage on qualifying products.
Parts & service support
Register your product and submit service requests through our support team.
Expert guidance
Talk to our team to match the right equipment to your operation.
Package Dimensions
| Length | 36.8" | 935mm |
| Width | 25.9" | 660mm |
| Height | 38.2" | 971mm |
| Weight | 260lbs | 118kg |
Oven Dimensions
| Length | 20" | 508mm |
| Width | 22.5" | 583mm |
| Height | 14.5" | 370mm |
Range Dimensions
| Length | 24" | 610mm |
| Width | 32" | 809mm |
| Height | 61.4" | 1559mm |
| Weight | 238lbs | 108kg |
Gas Specifications
| Gas Type | Propane Gas ,Natural Gas |
| Manifold Pressure | 11'' W.C. / 5'' W.C. |
| Gas Connection | 3/4'' |
Temperature
| 100°C ~ 300°C | 212°F ~ 572°F |
